| Compatible case size |
PS2 |
| Outline drawing |
150Wx86Hx175D |
| Weight |
2.2 kg typ |
| Input Voltage |
AC |
85-264V |
| DC |
24V(Dedicated battery package only) |
| Efficiency |
AC |
80% typ(AC100V)/85% typ(AC240V) |
| DC |
80% typ |
| Power factor |
96% min. at AC 100V/90% min. at AC 200V
|
| Input changeover system |
Worldwide |
| AC, DC input |
 |
| Safety |
UL60950-1, CSA C22.2 No.60950-1,CCC, CE Marking (IEC62368-1) |
| High frequency current regulation |
IEC61000-3-2 (Ed. 2.1) Class D and EN61000-3-2(A14)Class D compliant |
EMI standard
(Input feedback noise) |
VCCI-A FCC-A and EN55022-A compliant |
| CE marking |
Low Voltage Directive, EMC Directive |
| EMS immunity |
Electrostatic discharge: EN61000-4-2 compliant
Radiated,radio frequency electromagnetic fields: EN61000-4-3 compliant
Fast transient burst: EN61000-4-4 compliant
Lightning surge: EN61000-4-5 compliant
Conductive radio frequency electromagnetic fields: EN61000-4-6 compliant
Power source frequency magnetic immunity: EN61000-4-8 compliant
Voltage dips/regulations: EN61000-4-11 compliant |
| MTBF |
70,000H min |
| Operating temperature |
0 to 60 deg C (load derating: 100% at 45 deg C, 70% at 60 deg C) |
| Leakage current |
0.5mA max. at AC 100V, 1.0mA max. at AC 200V, 1.2mA max. at AC 240V
|
| Cooling systems |
Forced air cooling |
| Insulation |
AC input - FG/DC output: 1500 VAC for 1 minute,AC input - FG/DC output: 50M ohm min. |
| Output ground connection |
Connected chassis (FG) |
| Signal unit |
SU-RS (RS232C), SU-BU (buzzer), SU-US2 (USB) |
| Warranty |
Three years after delivery; the defective unit shall be repaired or replaced at our cost if defects belong to us. |
With +24V Output Nonstop Power Supply
:For description of function, click each icon
