| Compatible case size |
Other |
| Outline drawing |
84Wx45Hx180D |
| Weight |
0.55 kg typ |
| Input Voltage |
AC |
85-264V |
| Efficiency |
AC |
92% typ(AC100V)/94% typ(AC200V) |
| Power factor |
99% typ(AC100V)/94% typ(AC200V) |
| Input changeover system |
Worldwide |
| Safety |
UL62368-1, CSA62368-1 (c-UL) certified, CE Marking, UKCA Marking
EN62477-1, OVC III , PSE (ordinance clause 2) compliant |
| High frequency current regulation |
IEC61000-3-2 (edition 2.1) classA, EN61000-3-2 (A14) classA compliant |
EMI standard
(Input feedback noise) |
VCCI-B, FCC-B, CISPR32-B, EN55032-B compliant |
| CE marking |
Low Voltage Directive, EMC Directive,RoHS2.0 |
| EMS immunity |
Electrostatic discharge: IEC61000-4-2 compliant
Radiate, radio frequency electromagnetic fields: IEC61000-4-3 compliant
Fast transient burst: IEC61000-4-4 compliant
Lightning surge: IEC61000-4-5 compliant
Conductive radio frequency electromagnetic fields: IEC61000-4-6 compliant
Power source frequency magnetic immunity: IEC61000-4-8 compliant
Voltage dips and fluctuation: IEC61000-4-11 compliant |
| MTBF |
 |
| Operating temperature |
-10-70deg.C (at convection cooling), -10-70deg.C (at forced air cooling) |
| Leakage current |
0.06mA typ (100VAC), 0.12mA typ (200VAC) |
| Cooling systems |
Air-cooling without blower |
| Insulation |
3kVAC/1minute between input and output/RC,1.5kVAC/1minnute between input and FG,500VAC/1minute between each output /RC/FG |
| Output ground connection |
Capacitor grounding |
| Warranty |
Three years after delivery: If any defects belong to us, the defective unit shall be repaired or
replaced at our cost. |
AC-DC Converter
