Battery Data
Standard, specifications: For standard and specifications, click each item.
| Compatible case size |
Other |
| Outline drawing |
41Wx124Hx117.5D |
| Weight |
0.75 kg typ |
| Applied battery |
Lithium-ion battery |
| Nominal battery power voltage |
18VDC (3.6V 5 series) |
| Rating capacity |
2500mAh |
| Built in fuse rating |
 |
| Operating temperature |
10 to 45deg.C/10 to 90% |
| Storage temperature/humidity |
Storage within 1 year: -20 to +20 deg.C / humidity 10-95%
Storage within 90 days: -20 to +40 deg.C / humidity 10-95%
Storage within 30 days: -20 to +50 deg.C / humidity 10-95% |
| Warranty |
One year after delivery: If any defects belong to us, the defective unit shall be
repaired or replaced at our cost. Except for internal battery. |
Battery Package
