| Compatible case size |
PS2 |
| Outline drawing |
150Wx86Hx140D |
| Weight |
1.80 kg typ |
| Input Voltage |
AC |
85-264V |
| DC |
380V (Dedicated capacitor package only) |
| Efficiency |
AC |
73% typical at AC100V and 77% typical at AC240V |
| DC |
80% typical |
| Power factor |
99% typical at AC100V and 97% typical at AC240V |
| Input changeover system |
Worldwide |
| AC, DC input |
DC input is for dedicated capacitor package. |
| Safety |
UL60950, CSA C22.2 No.60950 (c-UL), EN60950, CE Marking (IEC62368-1) |
| High frequency current regulation |
Compliant with IEC61000-3-2 (Ed. 2.1) Class D and EN61000-3-2 (A14) Class D |
EMI standard
(Input feedback noise) |
Compliant with VCCI Class B FCC Rules Class B and EN55022 Class B |
| CE marking |
Low voltage and EMI directive and RoHS2.0 |
| EMS immunity |
Electrostatic discharge to meet EN61000-4-2
Radioactive radio-frequency electromagnetic fields to meet EN61000-4-3
Fast transient burst to meet EN61000-4-4
Lightning surge immunity to meet EN61000-4-5
Conductive radio-frequency electromagnetic field to meet EN61000-4-6
Power frequency magnetic field immunity to meet EN61000-4-8
Voltage dips and fluctuation to meet EN61000-4-11 |
| MTBF |
95,000H |
| Operating temperature |
0 to 45 deg C with full-load, and to 60 deg C with 70% of load |
| Leakage current |
0.5mA max. at AC100V, and 1mA max. at AC200V |
| Cooling systems |
Forced air cooling |
| Insulation |
 |
| Output ground connection |
Connected to chassis |
| Signal unit |
Supported for SU-RS (RS232C),SU-BU (buzzer),, SU-US2 (USB) |
| Warranty |
Three years after delivery. However, if defects belong to us, the defective unit shall be repaired or replaced at our cost. |
